Metamark MetaGuard MG-X Cylinder Cast Overlaminate, 63-inch Rolls
Metamark MetaGuard MG-X Cylinder Cast Overlaminate, 63-inch Rolls
SKU:MG-X-002-160
Couldn't load pickup availability
MetaGuard MG-X is a cylinder-cast soft PVC overlaminate matched with MetaWrap MD-X print film. The matched system is intended for vehicle graphics over compound curves and moderate recesses, subject to the manufacturer’s processing and application instructions. Its permanent clear solvent-based acrylic adhesive contains UV inhibitors.
- Film: Cylinder-cast soft PVC, 50 µm nominal
- Adhesive: Permanent clear solvent-based acrylic with UV inhibitors
- Release liner: Solventless kraft
- Matched print film: MetaWrap MD-X
Allow printed inks to cure and confirm suitability of the overlaminate for the print media. Follow the manufacturer’s cold-lamination and wrap-application guidance. Avoid overstretching the matched wrap system.
Roll options
- 63 in × 55 yd | Clear matte: MG-X-002-160
- 63 in × 55 yd | Clear gloss: MG-X-005-160
Manufacturer technical and application resources
- MetaGuard MG-X technical data sheet (PDF): family specifications, matched print film, ink-curing and lamination guidance.
- Application of Overlaminates (PDF): general laminator and handling guidance; the exact matched-system drying and installation instructions take precedence.
- MetaWrap MD-X vehicle-wrap application guide (PDF): installation guidance for the matched print-film and overlaminate system, not unrelated media.
- Metamark regional durability guide (PDF): climate-zone and exposure context; the family-sheet figures are not a blanket US finished-graphic guarantee.
- Cleaning and Maintenance of Vehicle Wraps (PDF): wrap-specific cleaning and aftercare precautions for printed graphics protected with a vinyl overlaminate.
Use the matched print-film and overlaminate instructions together. Allow the print to out-gas fully; the wrap-system drying requirement takes precedence over a shorter general interval. Follow the laminator, dry-installation and family-specific heat/post-heating directions. Test the actual ink, substrate and process.
This is MG-X, not MG-X-M. The MG-X sheet names solvent, eco-solvent and latex prints and also refers to UV in its application section; do not treat that as approval of every UV ink or unrelated print medium. The MD-X guide’s modest-recess limits remain applicable.
Manufacturer documents include metric family presentations and other constructions. They do not replace the exact US SKU, finish or roll dimensions listed above. These links do not create a bundled kit, guarantee stock availability or establish a finished-graphic warranty.
Matched companion products
Matched print film: MD-X white gloss, 63 in x 55 yd. The width and length match both MetaGuard MG-X finish options above. This is a conditional matched-system recommendation, not a kit or a universal vehicle-wrap capability claim.
About the application photo: Manufacturer MetaGuard MG-X family application example. Representative graphics only; exact finish, US sale roll and packaging are not shown.
