Metamark MetaWrap MD-X White Gloss Cylinder Cast Wrap Film, 63 in × 55 yd
Metamark MetaWrap MD-X White Gloss Cylinder Cast Wrap Film, 63 in × 55 yd
SKU:MD-X-100-160
Couldn't load pickup availability
MetaWrap MD-X is a cylinder-cast printable film for vehicle graphics over compound curves and moderate recesses. Its permanent grey MetaScape adhesive provides air-release channels and helps limit substrate show-through. The family is matched with MetaGuard MG-X overlaminate.
- SKU: MD-X-100-160
- Roll size: 63 in × 55 yd
- Finish: White Gloss (with Air-Egress)
- Film: Cylinder-cast vinyl, 50 µm nominal
- Adhesive: MetaScape permanent grey solvent-based acrylic with air-release channels
- Release liner: Structured layflat kraft with PE coating, 140 gsm nominal
- Matched overlaminate: MetaGuard MG-X
Test print and confirm substrate suitability. Allow inks to cure before lamination or vehicle application. Install dry, follow the manufacturer’s heat and post-heating guidance, and avoid overstretching.
Manufacturer technical and application resources
- MetaWrap MD-X technical data sheet (PDF): V1.2_26; exact family construction, printing, drying, dry application and storage.
- MetaWrap MD-X vehicle-wrap application guide (PDF): surface preparation, panel layout, installation and post-heating for this matched system.
- Metamark regional durability guide (PDF): climate-zone and exposure context; the family-sheet figures are not a blanket US finished-graphic guarantee.
- Cleaning and Maintenance of Vehicle Wraps (PDF): wrap-specific cleaning and aftercare precautions for printed graphics protected with a vinyl overlaminate.
Use the product-specific sheet and wrap guide together. Install dry, allow the printed film to out-gas fully before laminating and installing, and follow the family-specific fitting and post-heating instructions. A shorter general lamination drying interval must not replace the wrap-system guidance. Test the actual substrate and print process; do not overstretch.
The guide distinguishes air-release MD-X for modest recesses from MD-XB for deeper recesses. This white gloss MD-X-100-160 is not MD-XB or the non-MetaScape clear MD-X option.
Manufacturer documents include metric family presentations and other constructions. They do not replace the exact US SKU, finish or roll dimensions listed above. These links do not create a bundled kit, guarantee stock availability or establish a finished-graphic warranty.
Matched companion products
For the manufacturer-matched MD-X/MG-X system, see 63 in x 55 yd MG-X clear matte or MG-X clear gloss. Both listed options match this roll width and length. Confirm the exact ink, substrate and laminate combination before production; do not substitute unrelated wrap films or transfer the settings between MD-X and MDC.
About the application photo: Manufacturer MetaWrap MD-X family application example. Representative graphics only; exact finish, US sale roll and packaging are not shown.
