Metamark MD5-A Clear Gloss MetaScape Print Vinyl, 54 in × 55 yd
Metamark MD5-A Clear Gloss MetaScape Print Vinyl, 54 in × 55 yd
SKU:MD5A-105-137-50
Couldn't load pickup availability
MD5-A is a polymeric calendered vinyl for printed graphics on smooth flat or slightly curved surfaces. Its permanent MetaScape adhesive has air channels to help air escape and allows positioning during application. The family is matched with MetaGuard MG-700 overlaminates.
- SKU: MD5A-105-137-50
- Roll size: 54 in × 55 yd
- Finish: Clear Gloss
- Film: Polymeric calendered vinyl, 70 µm nominal
- Adhesive: MetaScape permanent solvent-based acrylic with air channels
- Release liner: Structured layflat kraft with PE coating, 140 gsm nominal
- Matched overlaminate: MetaGuard MG-700 family
Apply dry and unstressed. Not suitable over rivets or complex recesses, or recommended for low-energy surfaces such as polypropylene. Test print, allow inks to cure and confirm substrate suitability.
Manufacturer technical and application resources
- Metamark MD5-A technical data sheet (PDF): current V1.1_26 sheet explicitly including MD5A-105 Clear Gloss.
- Application to Glass precautions (PDF): glazing, coating, shading and heat-absorption checks; this general guide does not grant wet-application permission to dry-only films.
- Metamark regional durability guide (PDF): climate-zone and exposure context, not a blanket US finished-graphic guarantee.
- Cleaning and Maintenance of Vinyl (PDF): for printed graphics protected with a vinyl overlaminate, not cleaning directly on unprotected print.
Use the Clear Gloss MD5A-105 reference for this MetaScape air-channel film. Clear gloss is not an optical-clarity claim. Install dry and unstressed on suitable smooth flat or slightly curved surfaces; do not transfer standard-MD5 wet-application instructions. Rivets and complex recesses are excluded, and low-energy surfaces such as polypropylene are not recommended.
Follow product-specific printing and drying directions before application or lamination. Assess the actual glass type, coating, shading and print coverage before window use. The family MG-700 reference is not approval of every finish or ink system.
Manufacturer family documents may show metric presentations and other finishes or constructions. They do not replace the exact US SKU, offered configuration or roll dimensions above, establish current availability, or supply missing stock-specific attributes. Confirm the actual substrate, ink and complete graphic system before production.
About the application photo: Manufacturer MD5-A family application example. Representative graphics only; exact finish, US sale roll and packaging are not shown.
