Metamark
Metamark MD5-GB White Gloss MetaGlide Blockout Print Vinyl, 54 in × 55 yd
Metamark MD5-GB White Gloss MetaGlide Blockout Print Vinyl, 54 in × 55 yd
SKU:MD5G-B-137
Couldn't load pickup availability
MD5-GB is a polymeric blockout print vinyl with a grey MetaGlide microchannel adhesive. The air-release system helps with positioning, while the grey adhesive helps reduce substrate show-through. The family is matched with MetaGuard MG-700 overlaminates.
- SKU: MD5G-B-137
- Roll size: 54 in × 55 yd
- Finish: White Gloss
- Film: Polymeric calendered vinyl, 70 µm nominal
- Adhesive: MetaGlide microchannel permanent grey solvent-based acrylic
- Release liner: Structured PE layflat kraft
- Matched overlaminate: MetaGuard MG-700 family
For dry application only. Test print, allow inks to cure and confirm substrate suitability. Not recommended for low-energy surfaces such as polypropylene. Confirm the grade’s limits for the intended surface; no complex-recess suitability is assumed.
Manufacturer technical and application resources
- Metamark MD5-GB technical data sheet (PDF): current V1.1_26 grey MetaGlide microchannel family sheet.
- Metamark regional durability guide (PDF): climate-zone and exposure context, not a blanket US finished-graphic guarantee.
- Cleaning and Maintenance of Vinyl (PDF): for printed graphics protected with a vinyl overlaminate, not cleaning directly on unprotected print.
This is the MD5-GB MetaGlide blockout construction, not MD5-B standard adhesive or MD5-AB MetaScape. Use dry application only and verify the substrate; the sheet does not recommend low-energy surfaces such as polypropylene.
Test the print profile, allow solvents to dry fully before installation or lamination, and confirm the intended surface geometry and matched laminate. Do not infer complex-recess suitability from air release or substitute a shorter generic drying interval.
Manufacturer family documents may show metric presentations and other finishes or constructions. They do not replace the exact US SKU, offered configuration or roll dimensions above, establish current availability, or supply missing stock-specific attributes. Confirm the actual substrate, ink and complete graphic system before production.
About the application photo: Manufacturer MD5-GB family application example. Representative graphics only; exact finish, US sale roll and packaging are not shown.
